IP камера Dahua DH-SD59230S-HN скоростная купольная поворотная 2Мп с 30x оптическим увеличением с ИК подсветкой,PoE+

Model

DH-SD59212S-HN

DH-SD59220S-HN

DH-SD59230S-HN

Camera

Image Sensor

1/2.8” CMOS

Effective Pixels

1944(H) x 1092(V), 2Megapixels

Scanning System

Progressive

Electronic Shutter Speed

1/3 ~ 1/30,000s

Min. Illumination

Color: 0.05Lux@F1.6; B/W: 0.005Lux@F1.6

S/N Ratio

More than 55dB

Camera Features

Day/Night

Auto(ICR) / Color / B/W

Backlight Compensation

BLC / HLC / DWDR (Digital WDR)

White Balance

Auto, ATW, Indoor, Outdoor, Manual

Gain Control

Auto / Manual

Noise Reduction

Ultra DNR (2D/3D)

Privacy Masking

Up to 24 areas

Digital Zoom

16x

Lens

Focal Length

5.1mm~61.2mm
(12x Optical zoom)

5.5mm ~ 110.0mm
(20x Optical zoom)

4.3mm~129mm
(30x Optical zoom)

Max Aperture

F1.6~ F3.0

F1.6 ~ F3.5

F1.6~ F5.0

Focus Control

Auto / Manual

Angle of View

H: 51.3° ~ 4.64°

H: 51° ~ 2.60°

H: 65.1° ~ 2.34°

Close Focus Distance

100mm~ 1000mm

PTZ

Pan/Tilt Range

Pan: 0° ~ 360° endless; Tilt: -15° ~ 90°, auto flip 180°

Manual Control Speed

Pan: 0.1° ~300° /s; Tilt: 0.1° ~200° /s

Preset Speed

Pan: 400° /s; Tilt: 300° /s

Preset

300

PTZ Mode

5 Pattern, 8 Tour, Auto Pan, Auto Scan

Speed Setup

Human-oriented focal length/ speed adaptation

Power up Action

Auto restore to previous PTZ and lens status after power failure

Idle Motion

Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period

IR Distance

80m (DC12V)
100m (AC24V)

Video

Compression

H.264 / MJPEG

Resolution

1080P(1920×1080)/ 720P(1280×720) / D1(704×576/ 704×480) /CIF
(352×288/352×240)

Frame Rate

Main Stream

1080P/ D1 (1 ~ 25/30fps), 720P(1~50/60fps)

Sub Stream

D1/CIF(1 ~ 25/30fps)

Bit Rate

H.264: 448K ~ 8192Kbps, MJPEG: 5120K ~ 10240Kbps

Audio

Compression

G.711a / G.711Mu(32kbps)/ PCM(128kbps)

Interface

1/1 channel In/Out

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4/ IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x

Compatibility

ONVIF PSIA CGI

Max. User Access

20 users

Smart Phone

iPhone, iPad, Android, Windows Phone

Auxiliary Interface

Memory Slot

Micro SD, Max 64GB

Alarm

2/1 channel In/Out

General

Power Supply

AC24V/ DC12V+POE plus

Power Consumption

DC12V: 13W, 20W (IR on)
AC24V: 13W, 23W (IR on)

Working Environment

DC12V: -30ºC ~ 60ºC / Less than 90% RH
AC24V: -40ºC ~ 70ºC / Less than 90% RH

Ingress Protection

IP66

Dimensions

Φ186.0(mm) x 309(mm)

Weight

3.5kg
